1-20-25 Picked up a new Belimo actuator control. Installed it in the upstairs office lobby area. I had removed the existing one to use it in the chiropractor office the other day to get them up and running. This was just replaced the ones that I removed.

Sold 2 star furnace

Upon arrival the heat was not working. The homeowner explained that Ramon was out on Friday last week and he replaced the inducer motor and the blower motor/module. After he replaced both motors the system ran almost all weekend. On Sunday, the system stopped heating. When I arrived the unit had no power to it. I checked the breaker panel and found the furnace breaker was tripped. I reset the breaker and then tried testing the unit. As soon as the unit came on it made a loud humming noise following by a popping sound and smoke which was very alarming. I can’t say for 100% certain what caused this but the next option would be replacing the control board and another new blower motor and I don’t think they should put that much money into this system since is already 11 years old. Customer went over options for replacement with my Field Supervisor Jamie. He will get you taken care of the rest of the way today. If you have any questions or concerns please feel free to call us! Your LBA Tech

Quote to make the listed repairs to (4) unit heaters. Price includes parts and labor. Customer will provide a fork lift, cage and driver to access the units. These units cannot be fully tested without the listed repairs. The heating operation will be verified after the repairs are completed. Any further repairs if required will be quoted separately. Unit heater #4--serial not legible--replace the pilot assembly and flame sensor--$903.97 Unit heater #7--serial P99053300002--replace the room thermostat--$237.55 Unit heater #12--serial 15081010994--replace the room thermostat--$237.55 Unit heater #13--serial 15081010994--replace the room thermostat--$237.55 1-20-25 Unit heater #13 flue as been broken at the 90 bend shut gas of and will need to come out to repair flue 8 inch flue diameter Unit heater 7,12, and 13 all have new thermostats Unit heater 4 has new pilot assembly but found gas intake was higher then normal causing gas valve to not open due to the pressure of the gas

X

During Maintenance there was a high static reading on system. Customer did not wish to explore options based on cost.

Completed furnace maintenance and inspection. I cleaned up furnace and checked all components. Airflow pressure is failed on the system. Brought out supervisor to review situation

*(*))*)*(&)&&(&()&)*(&))&)$()&(&/&)&(&(&)&(&($)&)$’dj Notes will be formatted, m/ns added and emailed to Elle to replace the notes below. Photos and info will be emailed to Rick. A 815 1,2,4,5,&6 Fan motor for uh 5: Dayton Duty motor, m/n 3MO16A, mfg model# K55HXJBB4999, mfg. # D74 8, 115v 1ph, 3.0a, 1/6hp, rpm 1100/950 Fan motor unit #6: century motor, air over duty 40degC, m/n F48D71A01, hp 1/4, rot rev, serial # 07518M1, rpm 1075, frame 48Y, volts 115 1ph, amps 4.9 *(*(&($*$*$7$*($$*$($($$($($($*$*($($($(($( Unit # UH2 2 fans (1 completely missing) Fan motor, fan blade, fan guard and motor mount missing. The existing fan motor bearings slightly tight Flue pipe not attached to B-vent 10” flue Thermostat works Hx sooted Voltage present Breaker has been painted. I removed the paint but it is unreadable. Unit# UH #1 T-stat works Fan motor bearings good Hx ok Burners light and flames do not move when fan turns on Draft diverter functioning Flue gasses O2 13.6, CO 47, Flue pipe

Z

Customers furnace was down, thermostat blank and no indication light on board. Fuse was popped, found that low voltage wire was pinched and grounding out, revised wiring and replaced fuse. System turned on and operating normally, observed for 15 minutes and system operating normally now.

N

Completed light maintenance on units

Arrived to remedy an inoperable furnace. Upon inspection found a fault code stating a board error. Verified that the control board is receiving the proper power. Cycled power and the system started heating as designed. Let the system run and jump into maximum capacity. Set the thermostat lower than the room temperature and the furnace shut down as it should. Set system back to a comfortable temperature and the furnace fired exactly as it should. Furnace is functioning properly at this time.

Found that a gas shutoff was left in the off position. Turned it on and furnace fired as designed.

.

3T Gold 96 full system x2 *Up 2 16 SEER a/c w/2 stages of cooling paired w/ 96% furnaces w/ 2stages of heating and variable speed fan motors. *10 years parts warranty *Tankless water heater *2 bypass humidifiers

Arrived to do a performance maintenance. Set up for combustion analysis temperature split and static pressure tests. Found that the system is operating with failing static pressure. Reached out to a field supervisor to finish the diagnosis on the systems static pressure. Verified operation of all mechanical and electronic components of the furnace. Checked blower for cleanliness and to see if there is any play in the bearings. Found that the fan for both heating and cooling is coated in dust. Checked systems heat exchanger to ensure proper venting of flue gas. Found premature wear on the heat exchanger. Verified operation of the humidifier. Performed an electronic gas leak search. Found that a fitting next to the union closest to the furnace is leaking. Spoke with homeowner about the system. With homeowners approval disassembled the gas line piece by piece and tightened them into place. Performed another gas leak search and verified that the gas leak is sealed. Furnace is operational a

Installed 80% furnace cut out any rust on return and on case coil replaced with metal April air filter box, furnace box, gas, electrical flutes

Fixed sump Josiah installed

S

Got parts installed unit is up and running

Arrived to do a performance maintenance. Set up for combustion analysis temperature split and static pressure tests. Found that the system is operating with failing static pressure. Verified operation of all mechanical and electronic components of the furnace. Checked blower for cleanliness and to see if there is any play in the bearings. Found that the fan for both heating and cooling is coated in dust. Checked systems heat exchanger to ensure proper venting of flue gas. Found premature wear on the heat exchanger. Verified operation of the humidifier. Found that it is leaking due to a heavily calcified water panel. Spoke with homeowner about the system. Furnace is operational at this time.

Upon arrival I began the tune up. First, I ran a static pressure test. This unit is rated for a maximum of .2 and the system is testing at 1.3 which is way over the max allowed and the reason for this is because the system only has 4 supply vents that only go to the main floor so what this means is that there isn’t enough room to release the air into the home which makes the static pressure rise. Next, I checked the running amps on the blower motor and it checked out within specifications. I took a temperature split on the unit and it was within specs at 41 degrees. If you have any questions or concerns please feel free to call us! Your LBA Technician, Tyler Rickard P.S. No payment was due for todays visit. Customer paid with canned goods.I will drop these off at the shop later today. Have a great weekend!

Estimate

Nnn
